Original price was: ৳ 195,000.00.৳ 186,000.00Current price is: ৳ 186,000.00.
Looking for the DEYE 8KW SUN-8K-SG05LP1-EU-SM2 Hybrid Inverter in Bangladesh? This advanced 8kW hybrid solar inverter is designed to deliver reliable, efficient, and intelligent power management for residential and commercial solar systems. It supports both on-grid and off-grid operation, ensuring uninterrupted electricity during grid failures while maximizing solar energy utilization.
The DEYE 8KW SUN-8K-SG05LP1-EU-SM2 Hybrid Inverter features dual MPPT technology for higher solar energy harvesting, supports 48V lithium and lead-acid batteries, and offers high conversion efficiency for maximum energy savings. Its smart LCD display, built-in WiFi monitoring, remote management, and parallel operation capability make it an ideal choice for modern solar installations. The inverter is compatible with generators, allows time-of-use battery charging, and includes comprehensive protection against overload, short circuit, overheating, and voltage fluctuations for long-term reliability.
Whether you are installing a new solar power system or upgrading an existing one, the DEYE 8KW SUN-8K-SG05LP1-EU-SM2 Hybrid Inverter provides dependable performance, flexible battery compatibility, and intelligent energy management. Buy the DEYE 8KW Hybrid Solar Inverter at the best price in Bangladesh from Solar System BD and enjoy genuine products, professional installation, warranty support, and nationwide delivery.
| Model | SUN-7K-SG05LP1-EU-SM2 | SUN-7.6K-SG05LP1-EU | SUN-8K-SG05LP1-EU-SM2 | SUN-10K-SG05LP1-EU-SM2 |
| Battery Input Data | ||||
| Battery Type | Lead-acid or Lithium-ion | |||
| Battery Voltage Range(V) | 40-60 | |||
| Max.Charging Current(A) | 175 | 190 | 190 | 210 |
| Max.Discharging Current(A) | 175 | 190 | 190 | 210 |
| Charging Strategy for Li-ion Battery | Self-adaption to BMS | |||
| Number of battery input | 1 | |||
| PV String Input Data | ||||
|
Max. PV Access Power (W)
|
14000 | 15200 | 16000 | 20000 |
| Max PV Input Power（W） | 11200 | 12160 | 12800 | 16000 |
| Max PV Input Voltage（V） | 500 | |||
| Start-up Voltage（V） | 125 | |||
| MPPT Voltage Range（V） | 150-425 | |||
| Rated PV Input Voltage(V) | 370 | |||
| Max Operating PV Input Current（A） | 26+26 | |||
| Max Input Short-Circuit Current（A） | 34+34 | |||
| No.of MPP Trackers/No.of String Per MPP Tracker | 2/2+2 | |||
| AC Input/Output Data | ||||
| Rated AC Input/Output Active Power（W） | 7000 | 7600 | 8000 | 10000 |
| Max AC Input/Output Apparent Power （VA） | 7700 | 8360 | 8800 | 11000 |
| Rated AC Input/Output Current（A） | 31.9/30.5 | 34.5/33.1 | 36.4/34.8 | 45.5/43.5 |
| Max AC Input/Output Current（A） | 35/33.5 | 38/36.4 | 40/38.3 | 50/47.9 |
| Max Continuous AC Passthrough (grid to load)（A） | 50 | |||
| Peak Power (off-grid)（W） | 2 times of rated power,10s | |||
| Rated Input/Output Voltage/Range(V) | 220V/230 0.85Un-1.1Un | |||
| Grid Connection Form | L+N+PE | |||
| Rated Input/Output Grid Frequency/Range | 50Hz/45Hz-55Hz 60Hz/55Hz-65Hz | |||
| Power Factor Adjustment Range | 0.8 leading-0.8lagging | |||
| Total Current Harmonic Distortion THDi |
<3% (of nominal power)
|
|||
| DC Injection Current | <0.5%ln | |||
| Efficiency | ||||
| Max Efficiency | 97.6% | |||
| Euro Efficiency | 96.5% | |||
| MPPT Efficiency | ＞99% | |||
| Equipment Protection | ||||
|
Integrated
|
DC Reverse Polarity Protection, AC Output Overcurrent Protection, Thermal Protection, AC Output Overvoltage Protection, AC Output Short Circuit Protection, DC Component Monitoring, Arc Fault Circuit Interrupter (optional), Anti-islanding Protection, DC Switch, Insulation Impedance Detection, Residual Current Detection
|
|||
| Surge Protection Level | TYPE II(DC),TYPE II(AC) | |||
| Interface | ||||
| Communication Interface | RS485/RS232/CAN | |||
|
Monitor Mode
|
GPRS/WIFI/Bluetooth/4G/LAN(optional) | |||
| General Data | ||||
| Operating Temperature Range |
-40 to +60℃, >45℃ Derating
|
|||
| Permissible Ambient Humidity | 0~100% | |||
| Permissible Altitude | 2000m | |||
| Noise | ＜45 | |||
| Ingress Protection(IP) Rating | IP 65 | |||
| Inverter Topology | Non-Isolated | |||
| Over Voltage Category | OVC II(DC),OVC III(AC) | |||
| Cabinet size（W*H*D）[mm] | 366×589.5×237 (Excluding Connectors and Brackets) | |||
| Weight[kg] | 26.8 | |||
| Warranty | 5 Years/10 Years the Warranty Period Depends the Final Installation Site of Inverter, More Info Please Refer to Warranty Policy |
|||
| Type Of Cooling | Intelligent air cooling | |||
| Grid Regulation | IEC 61727,IEC 62116,CEI 0-21,EN 50549，NRS 097,RD 140,UNE 217002,OVE-Richtlinie R25,G99,VDE-AR-N 4105 | |||
| Safety EMC/Standard | IEC/EN 61000-6-1/2/3/4, IEC/EN 62109-1, IEC/EN 62109-2 | |||
